IRIS+™ Security Overview
16min
Cybersecurity is a field dedicated to protecting systems, networks, and data from digital attacks, damage, or unauthorized access. Here’s a broad overview of the key concepts and components involved in protecting IRIS+™ application and system:
- All endpoint communication based on HTTPS / WSS
- Certificate issued by a well-known CA (LetsEncrypt)
- Data transfer from/to the IRIS+™ Core is encrypted (TLS 1.3)
- Sensitive configuration data is encrypted (SHA-256)
- Input data is serialized to well-known structured types
- Input data validation to avoid injections
- Each service in the system is packed as an isolated container image hosted by the orchestrator (Kubernetes)
- Services in the cluster run as pods in different namespaces to comply with multi-tier application architecture:
1. App – all stateless services processing data in memory
2. Data – all stateful services holding data (DB, Messaging, Streaming)
- Kubernetes provides internal DNS and firewall rules to restrict communication across namespaces
- Nodes are tagged according to the logical namespace to ensure nodes are assigned to a specific namespace
- Customers may restrict traffic across nodes (physical/virtual) using an external firewall
- Every IRIS+™ user is authenticated using a login/password
- Users can enable TOTP-based second-factor
- Password must comply with a strict password policy
- Users are authorized to use their roles to access and perform actions on the data
- Access to the system requires a valid API Key (to identify the system) and Access Token (to identify the user/service account) with specific access to resources
- Sessions (identified by Access Token) are restricted to 20 minutes of Idle time
- Any user/service account action is logged in the audit log and kept for 60 days
- Each service running in the edge is packed as an isolated container image hosted by the orchestrator (Kubernetes) or Docker CE engine
- The host OS runs the minimal set of daemons required to run Kubernetes or Docker CE
- Access to the network configuration page is protected by Edge Credentials
- Access to the device configuration page is protected by the registered IRIS+™ user credentials
